Jinko 475W TIER-1 Mono PV Solar Module 2182×1029×35mm

Unlock the potential of solar energy with the Jinko 475W TIER-1 Mono PV Solar Module. Crafted for excellence, this top-tier solar panel delivers unmatched efficiency and durability for residential and commercial applications.

Key Features:

• Superior Efficiency: Boasts up to 21.16% module efficiency for optimal energy production.
• Innovative TR Technology: Tiling Ribbon technology combined with Half Cell design reduces cell gaps, enhancing efficiency.
• 9BB Technology: Minimises the distance between bus bars and finger grid lines, resulting in higher power output and reliability.
• Robust Construction: Engineered to endure extreme weather conditions, withstanding wind loads up to 2400 Pascal and snow loads up to 5400 Pascal.

Specifications:

• Dimensions: 2182×1029×35mm
• Weight: 25 kg
• Cell Type: P-type Mono-crystalline, 156 (2×78) cells
• Power Output: 475W
• Voltage at Pmax: 43.38V
• Current at Pmax: 10.95A
• Open-circuit Voltage: 52.24V
• Short-circuit Current: 11.77A
• Module Efficiency: 21.16%
• Operating Temperature: -40°C to +85°C
• Maximum System Voltage: 1000/1500VDC (IEC)
• Power Tolerance: 0~+3%
• Temperature Coefficients:
  • Pmax: -0.35%/℃
  • Voc: -0.28%/℃
  • Isc: 0.048%/℃

Warranty:

• 12-Year Product Warranty
• 25-Year Linear Power Warranty: Guarantees only 2% degradation in the first year and 0.55% annual degradation thereafter, ensuring 84.8% of the original power output by year 25.

Certification:

• ISO9001:2015, ISO14001:2015, ISO45001:2018 certified
• IEC61215, IEC61730 certified

Why Choose Jinko Solar?

Opting for the Jinko 475W TIER-1 Mono PV Solar Module means choosing a product that offers reliability, high efficiency, and long-term energy savings. Perfect for anyone looking to reduce their carbon footprint and achieve energy independence.

Switch to a cleaner, more efficient energy source today! Order your Jinko 475W TIER-1 Mono PV Solar Module now and start enjoying the benefits of solar power.
