🧠 Deye HVB750V/100A-EU Cluster Control Box – High Voltage Battery Manager

The Deye HVB750V/100A-EU Cluster Control Box is the central BMS communication hub for managing up to 12 high-voltage battery modules in Deye’s energy storage systems. This smart controller ensures safe, synchronised operation between batteries and hybrid inverters — all while simplifying cable management and installation.

Built for integration with Deye’s HV battery racks and compatible inverters, this is your brain of the battery bank.

⚡ Key Features & Benefits:

• ✅ Manages 3 to 12 High Voltage Battery Modules

Communicates battery status, SOC, protection triggers, and temp data to the inverter.

• ✅ High Voltage Support (Max 750V)

Designed to manage systems with up to 750V DC output, ideal for powerful hybrid and commercial setups.

• ✅ 100A Discharge Support

Handles large current loads with smart protection layers built-in.

• ✅ Smart BMS Communication

RS485 and CAN interfaces ensure real-time data flow and fault reporting.

• ✅ Includes Preconfigured Cabling

Comes with battery busbars and communication cables for streamlined installation.

• ✅ Supports Parallel Racks (Optional)

Expand storage capacity across multiple stacks with proper BMS syncing.

🧰 Technical Specifications:

Model HVB750V/100A-EU

Battery Modules Supported 3–12 (HV type)

System Voltage Range 153.6V to 750V

Max Discharge Current 100A

Communication Protocols RS485 / CAN

Communication with Inverter Deye Hybrid 3Ph (HV models)

Included Accessories Power & comms cables, connectors

Mounting Cabinet or wall

Protection Features Overvoltage, Overcurrent, Temp, Short Circuit

Certifications CE, RoHS, IEC standards

Warranty 5 Years

💡 Ideal For:

• Deye HV battery rack installations

• High-voltage hybrid inverter systems

• Installers needing full HV battery control & communication

• Solar + storage projects with large capacity requirements

🔌 High Voltage. High Intelligence.

The Deye HVB750V/100A-EU Cluster Control Box brings control, protection, and smart integration to your HV battery setup. Plug it in and let the system think for itself.
