🔍 Sigen 3-Phase Power Sensor – Without CTs (173–480V AC)

High-Precision Power Monitoring for AI-Driven Solar Systems

The Sigen Power Sensor delivers accurate 3-phase power detection for residential, commercial, and industrial solar setups. It integrates effortlessly with Sigenergy devices and supports fast-response grid interaction, real-time monitoring, and AI-powered energy management — all in a compact DIN-rail mount form factor.

✅ Key Features:

• Compatible with 3P3W & 3P4W Grid Systems

• Wide Voltage Range: 173–480V AC | Frequency: 50/60Hz

• 1% Power Accuracy | 0.5% Voltage & Current Accuracy

• 100 ms Data Refresh Rate – Near-instantaneous feedback

• LCD Display – Real-time data at a glance

• Plug-and-Play with Sigenergy Systems – No configuration required

• RS485 Communication (Modbus RTU) – Industrial-standard connectivity

• Supports Export/Import Limiting – For grid compliance

• DIN Rail Mounted – Easy installation into standard enclosures

⚙️ Technical Specs:

• Communication Interface: RS485

• Baud Rate: 9600 bps

• Power Accuracy: ±1%

• Voltage & Current Accuracy: ±0.5%

• Frequency Accuracy: ±0.2%

• Operating Temp: -30°C to +60°C

• Storage Temp: -40°C to +85°C

• Relative Humidity: 0–90% RH (non-condensing)

• Ingress Protection: IP51

• Dimensions: 72 × 94.5 × 65 mm

• Weight: ~0.2 kg

• Installation: 35mm DIN rail

• Compliance: EN 61010-1:2010, EN 61010-2-030:2010
